MODU/DECK
Steel Low Profile Vehicle Scales
Accurate. Flexible. Exceptional.
Compact, Corrosion-Resistant & Rugged
Modu-Deck low profile steel scales are made to last for years of tough everyday use. Their flexible design makes them easy to expand and move as business needs change. Plus, installation is straightforward and doesn’t require expensive pit renovation.
But it’s the Modu-Deck’s parallel link suspension and rocker fulcrum load cell that makes this series of scale supremely accurate. Its double-link 360º rotation suspension prevents off-centre side load weighing mistakes while its rocker fulcrum load cell eliminates the main source of weight errors.
AMD 6 Series Modu-Deck Pitless Side Access Steel Deck Truck Scale; 110,000 lb CLC Rating
Standard Features
- Modular deck design with 10’ to 25’ factory prefabricated modules
- Nine 12” wide flange main beams
- Installation height is 18½” with 4” clearance underside, available 4” to 10”
- Height as low as 12” available
- Width from 10’ up to 16’
- Hermetically sealed 75k SE double link beam load cells with armoured cable standard
- Side access to load cells, junction boxes, bumper bolts and anchor bolts
- Polycarbonate summing boxes comes with gore vents and PVC conduit
- Maximum capacity for single modules 80 ton, two or more modules 135 ton
- NTEP-approved Concentrated Load Capacity of 110,000 lb
- Home run cable NOT INCLUDED
- NTEP CC 94-132, Class IIIL, 10,000 d
Options
- Guiderails
- Hanging walkways
- Side skirting
- Surge protection
- Extended warranties
- Portable foundations
- Structural upgrades
- Custom paint systems
- Grain dumps
Modu-Deck Load Cells
The heart of any weighing device is the load sensing element. The Modu-Deck parallel link suspension and rocker fulcrum load cell provide a unique and vastly superior load sensing system. The double link 360º rotation suspension eliminates off-centre side load weighing errors created by thermal expansion of the weighbridge and accelerating or braking vehicles. The link suspension promotes return to zero, linearity, back weighing and enhances overall accuracy.
Ease of installation, ease of maintenance and sustained accuracy are trademarks of the system, which has proven itself in thousands of installations.
